Taylor Approximation

17.1 INTRODUCTION
17.2 LECTURE
17.3 EXAMPLES
EXERCISES

17.1 INTRODUCTION

17.1.1 How Linearity Helped Feynman Conquer the Cube Root

According to legend¹, Richard Feynman got into the challenge to compute the cube root of $1729.03$ against an Abacus computation. By using linear approximation and a bit of luck, he could get $12.002384$ using paper and pencil. The actual cube root is $12.002383785691718123057$ . How did Feynman do it? The secret is in linear approximation. This means that we approximate a function like $f (x) = x^{1 / 3}$ with a linear function. The same can be done with functions of several variables. The linear approximation if of the form L(x)=f(a)+f^{\prime}(a)(x-a).

Illustration for Taylor Approximation — **Figure 1.** The Abacus scene in the movie "Infinity".

17.1.2 Beyond Linear Approximations

One can also do higher order approximations. The function $f (x) = e^{x}$ for example has the linear approximation $L (x) = 1 + x$ at $a = 0$ and the quadratic approximation $Q (x) = 1 + x + x^{2} / 2$ at $a = 0$ . To get the quadratic term, we just need to make sure that the first and second derivative at $x = a$ agree. This gives the formula Q(x)=f(a)+f^{\prime}(a)(x-a)+f^{\prime \prime}(a)(x-a)^{2} / 2. Indeed, you can check that $f (x)$ and $Q (x)$ have the same first derivatives and the same second derivatives at $x = a$ . A degree $n$ approximation is then the polynomial $P_{n} (x) = \sum_{k = 0}^{n} f^{(k)} (a) \frac{(x - a)^{k}}{k!} .$ For the function $e^{x}$ for example, we have the $m$ ’th order approximation $e^{x} = 1 + x + x^{2} / 2! + x^{3} / 3! + \dots + x^{n} / n! .$

17.1.3 Multivariable Approximations

The same can be done in higher dimensions. Everything is the same. We just have to use the derivative $d f$ rather than the usual derivative f^{\prime}. We look here only at linear and quadratic approximation of functions $ℝ^{n} \to ℝ$ The linear approximation is then $L (x) = f (a) + \nabla f (a) (x - a)$ where $\nabla f (a) = d f (a) = [f_{x_{1}} (a), \dots, f_{x_{n}} (a)]$ is the Jacobian matrix, which ii a row vector. Now, since we can see $d f (x) : ℝ^{n} \to ℝ^{n}$ the second derivative is a matrix $d^{2} f (x) = H (x)$ . It is called the Hessian. It encodes all the second derivatives $H_{i j} (x) =$ $f_{x_{i} x_{j}}$ .

17.2 LECTURE

17.2.1 Unveiling the Multidimensional Taylor Formula

Given a function $f : ℝ^{m} \to ℝ^{n}$ , its derivative $d f (x)$ is the Jacobian matrix. For every $x \in ℝ^{m}$ , we can use the matrix $d f (x)$ and a vector $v \in ℝ^{m}$ to get $D_{v} f (x) =$ $d f (x) v \in ℝ^{m}$ . For fixed $v$ , this defines a map $x \in ℝ^{m} \to d f (x) v \in ℝ^{n}$ , like the original $f$ . Because $D_{v}$ is a map on $𝒳 = {all functions from ℝ^{m} \to ℝ^{n}},$ one calls it an operator. The Taylor formula $f (x + t) = e^{D t} f (x)$ holds in arbitrary dimensions:

Theorem 1. $f (x + t v) = e^{D_{v} t} f = f (x) + \frac{D_{v} t f (x)}{1!} + \frac{D_{v}^{2} t^{2} f (x)}{2!} + \dots$

Proof. It is the single variable Taylor on the line $x + t v$ . The directional derivative $D_{v} f$ is there the usual derivative as $lim_{t \to 0} [f (x + t v) - f (x)] / t = D_{v} f (x) .$ Technically, we need the sum to converge as well: like functions built from polynomials, $\sin$ , $\cos$ , $\exp$ . ◻

17.2.2 Tensors and the Multidimensional Taylor Series Representation

The Taylor formula can be written down using successive derivatives $d f$ , $d^{2} f$ , $d^{3} f$ also, which are then called tensors. In the scalar case $n = 1$ , the first derivative $d f (x)$ leads to the gradient $\nabla f (x)$ , the second derivative $d^{2} f (x)$ to the Hessian matrix $H (x)$ which is a bilinear form acting on pairs of vectors. The third derivative $d^{3} f (x)$ then acts on triples of vectors etc. One can still write as in one dimension

Theorem 2. f(x)=f(x_{0})+f^{\prime}(x_{0})(x-x_{0})+f^{\prime \prime}(x_{0}) \frac{(x-x_{0})^{2}}{2 !}+\cdots

if we write $f^{(k)} = d^{k} f$ . For a polynomial, this just means that we first write down the constant, then all linear terms then all quadratic terms, then all cubic terms etc.

17.2.3 The Local Approximation Through Linearization

Assume $f : ℝ^{m} \to ℝ$ and stop the Taylor series after the first step. We get $L (x_{0} + v) = f (x_{0}) + \nabla f (x_{0}) \cdot v .$ It is custom to write this with $x = x_{0} + v$ , $v = x - x_{0}$ as $L (x) = f (x_{0}) + \nabla f (x_{0}) \cdot (x - x_{0})$ This function is called the linearization of $f$ . The kernel of $L - f (x_{0})$ is a linear manifold approximating the surface ${x ∣ f (x) - f (x_{0}) = 0} .$ If $f : ℝ^{m} \to ℝ^{n}$ , then the just said can be applied to every component $f_{i}$ of $f$ , with $1 \leq i \leq n$ . One can not stress enough the importance of this linearization.²

17.2.4 Getting Even Closer: Quadratic Approximations with Hessians

If we stop the Taylor series after two steps, we get the function $Q (x + v) = f (x) + d f (x) \cdot v + v \cdot d^{2} f (x) \cdot v / 2.$ The matrix $H (x) = d^{2} f (x)$ is called the Hessian matrix at the point $x$ . It is also here custom to eliminate $v$ by writing $x = x_{0} + v$ . $Q (x) = f (x_{0}) + \nabla f (x_{0}) \cdot (x - x_{0}) + (x - x_{0}) \cdot H (x_{0}) (x - x_{0}) / 2$ is called the quadratic approximation of $f$ . The kernel of $Q - f (x_{0})$ is the quadratic manifold $Q (x) - f (x_{0}) = x \cdot B x + A x = 0,$ where $A = d f$ and $B = d^{2} f / 2$ . It approximates the surface ${x ∣ f (x) - f (x_{0}) = 0}$ even better than the linear one. If $| x - x_{0} |$ is of the order $ϵ$ , then $| f (x) - L (x) |$ is of the order $ϵ^{2}$ and $| f (x) - Q (x) |$ is of the order $ϵ^{3}$ . This follows from the exact Taylor with remainder formula.³

17.2.5 The Tangent Plane to a Surface

To get the tangent plane to a surface $f (x) = C$ one can just look at the linear manifold $L (x) = C$ . However, there is a better method:

The tangent plane to a surface $f (x, y, z) = C$ at $(x_{0}, y_{0}, z_{0})$ is $a x + b y + c z =$ $d$ , where $[a, b, c]^{T} = \nabla f (x_{0}, y_{0}, z_{0})$ and $d = a x_{0} + b y_{0} + c z_{0}$ .

17.2.6 How Gradients Help Find Tangent Planes to Surfaces

This follows from the fundamental theorem of gradients:

Theorem 3. The gradient $\nabla f (x_{0})$ of $f : ℝ^{m} \to ℝ$ is perpendicular to the surface $S = {f (x) = f (x_{0}) = C}$ at $x_{0}$ .

Proof. Let $r (t)$ be a curve on $S$ with $r (0) = x_{0}$ . The chain rule assures d / d t f(r(t))=\nabla f(r(t)) \cdot r^{\prime}(t). But because $f (r (t)) = c$ is constant, this is zero assuring r^{\prime}(t) being perpendicular to the gradient. As this works for any curve, we are done. ◻

17.3 EXAMPLES

Example 1. Let $f : ℝ^{2} \to ℝ$ be given as $f (x, y) = x^{3} y^{2} + x + y^{3}$ . What is the quadratic approximation at $(x_{0}, y_{0}) = (1, 1)$ ? We have $d f (1, 1) = [4, 5]$ and \begin{aligned} \nabla f(1,1)&=\left[\begin{array}{l} f_{x} \\ f_{y} \end{array}\right]=\left[\begin{array}{l} 4 \\ 5 \end{array}\right],\\ H(1,1)&=\left[\begin{array}{ll} f_{x x} & f_{x y} \\ f_{y x} & f_{y y} \end{array}\right]=\left[\begin{array}{ll} 6 & 6 \\ 6 & 8 \end{array}\right]. \end{aligned}

The linearization is $L (x, y) = 4 (x - 1) + 5 (y - 1) + 3.$ The quadratic approximation is $Q (x, y) = 3 + 4 (x - 1) + 5 (y - 1) + 6 (x - 1)^{2} / 2 + 12 (x - 1) (y - 1) / 2 + 8 (y - 1)^{2} / 2.$ This is the situation displayed to the left in Figure (17.2). For $v = [7, 2]^{T}$ , the directional derivative \begin{aligned} D_{v} f(1,1)&=\nabla f(1,1) \cdot v\\ &=[4,5]^{T} \cdot[7,2]=38. \end{aligned} The Taylor expansion given at the beginning is a finite series because $f$ was a polynomial: \begin{aligned} f([1,1]+t[7,2])&=f(1+7 t, 1+2 t)\\ &=3+38 t+247 t^{2}+1023 t^{3}+1960 t^{4}+1372 t^{5}. \end{aligned}

Example 2. For $f (x, y, z) = - x^{4} + x^{2} + y^{2} + z^{2}$ , the gradient and Hessian are \begin{aligned} \nabla f(1,1,1)&=\left[\begin{array}{l} f_{x} \\ f_{y} \\ f_{z} \end{array}\right]=\left[\begin{array}{l} 2 \\ 2 \\ 2 \end{array}\right],\\ H(1,1,1)&=\left[\begin{array}{lll} f_{x x} & f_{x y} & f_{x z} \\ f_{y x} & f_{y y} & f_{y z} \\ f_{z x} & f_{z y} & f_{z z} \end{array}\right]=\left[\begin{array}{ccc} -10 & 0 & 0 \\ 0 & 2 & 0 \\ 0 & 0 & 2 \end{array}\right]. \end{aligned}

The linearization is $L (x, y, z) = 2 - 2 (x - 1) + 2 (y - 1) + 2 (z - 1) .$ The quadratic approximation $Q (x, y, z) = 2 - 2 (x - 1) + 2 (y - 1) + 2 (z - 1) + (- 10 (x - 1)^{2} + 2 (y - 1)^{2} + 2 (z - 1)^{2}) / 2$ is the situation displayed to the right in Figure (17.2).

Example 3. What is the tangent plane to the surface $f (x, y, z) = 1 / 10$ for \begin{aligned} f(x, y, z)&=10 z^{2}-x^{2}-y^{2}+100 x^{4}-200 x^{6}+100 x^{8}-200 x^{2} y^{2}+200 x^{4} y^{2}+100 y^{4}\\ &=1 / 10 \end{aligned} at the point $(x, y, z) = (0, 0, 1 / 10)$ ? The gradient is $\nabla f (0, 0, 1 / 10) = [\begin{array}{l} 0 \\ 0 \\ 2 \end{array}] .$ The tangent plane equation is $2 z = d$ , where the constant $d$ is obtained by plugging in the point. We end up with $2 z = 2 / 10$ . The linearization is $L (x, y, z) = 1 / 20 + 2 (z - 1 / 10)$ .

EXERCISES

Exercise 1. Let $r (t) = [3 t + \cos (t), t + 4 \sin (t)]^{T}$ be a curve and $f ([x, y]^{T}) = {[x^{3} + y, x + 2 y + y^{3}]}^{T}$ be a coordinate change.

Compute v=r^{\prime}(0) at $t = 0$ , then $d f (x, y)$ and $A = d f (r (0))$ and d f(r(0)) r^{\prime}(0)=A v.
Compute $R (t) = f (r (t))$ first, then find w=R^{\prime}(0). It should agree with a).

Exercise 2.

The surface $f (x, y, z) = x^{2} + \frac{y^{2}}{4} + \frac{z^{2}}{9} = 4 + 1 / 4 + 1 / 9$ is an ellipsoid. Compute $z_{x} (x, y)$ at the point $(x, y, z) = (2, 1, 1)$ using the implicit differentiation rule. (Use the formula).
Apply the Newton step 3 times starting with $x = 2$ to solve the equation $x^{2} - 2 = 0$ .

Exercise 3. Evaluate without technology the cube root of $1002$ using quadratic approximation. Especially look how close you are to the real value.

Exercise 4.

Find the tangent plane to the surface $f (x, y, z) =$ $\sqrt{x y z} = 60$ at $(x, y, z) = (100, 36, 1)$ .
Estimate $\sqrt{100.1 \cdot 36.1 \cdot 0.999}$ using linear approximation (compute $L (x, y, z)$ rather than $f (x, y, z)$ .)

Exercise 5. Find the quadratic approximation $Q (x, y)$ of $f (x, y) = x^{3} + x^{2} y + x^{2} + y^{2} - 2 x + 3 x y$ at the point $(1, 2)$ by computing the gradient vector $\nabla f (1, 2)$ and the Hessian matrix $H (1, 2)$ . The vector $\nabla f (1, 2)$ is a $1 \times 2$ matrix (row vector) and the Hessian matrix $H (1, 2)$ is a $2 \times 2$ matrix.

Feynmans book "What do you care what other people think".↩︎
Again: the linearization idea is utmost important because it brings in linear algebra.↩︎
If $f \in C^{n + 1}$ , $f (x + t) = \sum_{k = 0}^{n} f^{(k)} (x) t^{k} / k! + \int_{0}^{t} (t - s)^{n} f^{(n + 1)} (x + s) / n! d s .$ (prove this by induction!)↩︎
